Narrow Width Micro Stainless Steel Filter Screen 200 - 400 Mesh Ultra Fine for Filter Cartridge and Mini Equipment

Name: Narrow Width Micro Stainless Steel Filter Screen 200 400 Mesh Ultra Fine for Filter Cartridge and Mini Equipment
Brand: chuangyi
Price: 1 USD

Quality Narrow Width Micro Stainless Steel Filter Screen 200 - 400 Mesh Ultra Fine for Filter Cartridge and Mini Equipment for sale

Model Number : CYSS114

Additional Properties : Low flow resistance, high flow velocity, and resistance to material erosion

MOQ : 1

Delivery Time : 7-10work days

Mesh Size : 0.03mm - 0.08mm

Payment Terms : L/C,T/T,,D/A,D/P

Mesh Count : 200-400 mesh

Price : $1-$20

Material : 316 Stainless Steel

Supply Ability : Daily production of 1000meters

width : 0.3m / 0.5m (narrow width custom sizes available)

Certification : ISO 9001, ISO 14001, ISO45001, SGS

Wire Diameter : 0.03mm - 0.08mm

Place of Origin : China

Additional Attributes : Precise dimensions, flat mesh surface, compatible with rolled filter cartridges, no dust shedding

Brand Name : chuangyi

Technology : Ultra-fine filament precision weaving

Packaging Details : rolling around paper tube first, moisture-proof paper outside or plastic fabrics, customed packing available

Contact Now

Narrow Width Micro Stainless Steel Filter Screen 200 - 400 Mesh Ultra Fine for Filter Cartridge and Mini Equipment

Stainless steel filter screen Description

Anping County Chuangyi Hardware Products Co., Ltd. mainly produces stainless steel filter screens.This narrow-width micro filter mesh is customized for small precision equipment and filter cartridges. With ultra-fine 200-400 mesh, it can capture micron-level tiny impurities. Made of high-purity 316 stainless steel, it has excellent chemical resistance and will not release contaminants. The narrow fixed width features precise dimension tolerance, flat mesh surface without warping, perfectly suitable for rolling, cutting and processing into various miniature filter elements.

Products name	Stainless Steel Filter Screen
material	316 Stainless Steel
Mesh Count	200-400 mesh
Width	0.3m / 0.5m (narrow width custom sizes available)
Mesh Size	0.03mm - 0.08mm
Wire Diameter	0.03mm - 0.08mm
Technology	Ultra-fine filament precision weaving
Additional Attributes	Precise dimensions, flat mesh surface, compatible with rolled filter cartridges, no dust shedding
Special service	OEM ODM

Features

Narrow, custom-designed dimensions, specifically for filter cartridges and small instruments.
Ultra-high mesh count enables micron-level ultra-precision filtration.
Made of 316 stainless steel, resistant to various chemical reagents, ensuring high cleanliness.
Dense weave with no shedding, guaranteeing the purity of the filter media.
High mesh flatness facilitates secondary processing and assembly.

Narrow Width Micro Stainless Steel Filter Screen 200 - 400 Mesh Ultra Fine for Filter Cartridge and Mini Equipment

Mesh/Inch	Wire Diameter		Aperture		Open area	weigh(LB)100square foot
	Inch	MM	Inch	MM
1×1	0.08	2.03	0.92	23.37	84.6	41.1
2×2	0.063	1.6	0.437	11.1	76.4	51.2
3×3	0.054	1.37	0.279	7.09	70.1	56.7
4×4	0.063	1.6	0.187	4.75	56	104.8
4×4	0.047	1.19	0.203	5.16	65.9	57.6
5×5	0.041	1.04	0.159	4.04	63.2	54.9
6×6	0.035	0.89	0.132	3.35	62.7	48.1
8×8	0.028	0.71	0.097	2.46	60.2	41.1
10×10	0.025	0.64	0.075	1.91	56.3	41.2
10×10	0.02	0.51	0.08	2.03	64	26.1
12×12	0.023	0.584	0.06	1.52	51.8	42.2
12×12	0.02	0.508	0.063	1.6	57.2	31.6
14×14	0.023	0.584	0.048	1.22	45.2	49.8
14×14	0.02	0.508	0.051	1.3	51	37.2
16×16	0.018	0.457	0.0445	1.13	50.7	34.5
18×18	0.017	0.432	0.0386	0.98	48.3	34.8
20×20	0.02	0.508	0.03	0.76	36	55.2
20×20	0.016	0.406	0.034	0.86	46.2	34.4
24×24	0.014	0.356	0.0277	0.7	44.2	31.8
30×30	0.013	0.33	0.0203	0.52	37.1	34.8
30×30	0.012	0.305	0.0213	0.54	40.8	29.4
30×30	0.009	0.229	0.0243	0.62	53.1	16.1
35×35	0.011	0.279	0.0176	0.45	37.9	29
40×40	0.01	0.254	0.015	0.38	36	27.6
50×50	0.009	0.229	0.011	0.28	30.3	28.4
50×50	0.008	0.203	0.012	0.31	36	22.1
60×60	0.0075	0.191	0.0092	0.23	30.5	23.7
60×60	0.007	0.178	0.0097	0.25	33.9	20.4
70×70	0.0065	0.165	0.0078	0.2	29.8	20.8
80×80	0.0065	0.165	0.006	0.15	23	23.2
80×80	0.0055	0.14	0.007	0.18	31.4	16.9
90×90	0.005	0.127	0.0061	0.16	30.1	15.8
100×100	0.0045	0.114	0.0055	0.14	30.3	14.2
100×100	0.004	0.102	0.006	0.15	36	11
100×100	0.0035	0.089	0.0065	0.17	42.3	8.3
110×110	0.004	0.1016	0.0051	0.1295	30.7	12.4
120×120	0.0037	0.094	0.0064	0.1168	30.7	11.6
150×150	0.0026	0.066	0.0041	0.1041	37.4	7.1
160×160	0.0025	0.0635	0.0038	0.0965	36.4	5.94
180×180	0.0023	0.0584	0.0033	0.0838	34.7	6.7
200×200	0.0021	0.0533	0.0029	0.0737	33.6	6.2
250×250	0.0016	0.0406	0.0024	0.061	36	4.4
270×270	0.0016	0.0406	0.0021	0.0533	32.2	4.7
300×300	0.0051	0.0381	0.0018	0.0457	29.7	3.04
325×325	0.0014	0.0356	0.0017	0.0432	30	4.4
400×400	0.001	0.0254	0.0015	0.037	36	3.3
500×500	0.001	0.0254	0.001	0.0354	25	3.8
635×635	0.0008	0.0203	0.0008	0.0203	25	2.63

Applications

Precision filter elements and cartridges rolling processing
Laboratory miniature filtration instruments
Electronic equipment cooling oil filtration
Small spray and atomizing device filter screens
Medical micro fluid filtration components

Narrow Width Micro Stainless Steel Filter Screen 200 - 400 Mesh Ultra Fine for Filter Cartridge and Mini Equipment

FAQ

1.Is this narrow mesh specially made for filter cartridges?

Exactly. Fixed narrow width, flat surface and precise size are perfect for rolling and processing into miniature filter elements.

2.Will tiny wire scraps fall off during use?

Adopting ultra-fine precision weaving, no debris shedding, which guarantees the purity of filtered liquid.

3.Can it filter micron-sized particles?

200-400 ultra-high mesh can effectively capture micron-level fine impurities for precision filtration.
